Product Summary

The G6A-474P-24VDC is a low signal relay.

Parametrics

G6A-474P-24VDC absolute maximum ratings: (1)Carry current: 3 A; (2)Max. operating voltage: 250 VAC, 220 VDC; (3)Max. operating current: 2 A 1 A; (4)Max. switching capacity: 125 VA, 60 W 62.50 VA, 30 W; (5)Min. permissible load (See note): 10 μA, 10 mVDC.

Features

G6A-474P-24VDC features: (1)High sensitivity — can be driven by digital circuits; (2)Low-profile design allows use in 12.70 mm PC board rack; (3)Surge withstand voltage meets FCC Part 68 regulation; (4)Units can be mounted side by side due to low magnetic leakage; (5)Special models available for low thermoelectromotive force; (6)Unique moving loop (permanent magnet)armature reduces relay size, magnetic interference, and contact bounce time; (7)Single or dual coil winding types available; (8)RoHS Compliant.

Diagrams

G6A-474P-24VDC pin connection
