DS80C320QCL

fast 80C31/80C32-compatible microcontroller, 6.0V, 45 mA, 121 ns, PLCC-44

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.68~3.79 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.68~3.79

PartNumber:: DS80C320QCL

Brand:: Dallas Semiconductor - Maxim | Pack: PLCC | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. sendy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-11

From Other Seller

Part Number:DS80C320QCL
US $1.68 - 3.79
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DS80C320QCL is a fast 80C31/80C32-compatible microcontroller. Wasted clock and memory cycles have been removed using a redesigned processor core. As a result, every 8051 instruction is executed between 1.5 and 3 times faster than the original for the same crystal speed. Typical applications will see a speed improvement of 2.5 times using the same code and same crystal. The DS80C320QCL offers a maximum crystal rate of 33 MHz, resulting in apparent execution speeds of 82.5 MHz (approximately 2.5X). The DS80C320QCL is pin-compatible with all three packages of the standard 80C32 and offers the same timer/counters, serial port, and I/O ports. In short, the device is extremely familiar to 8051 users but provides the speed of a 16-bit processor.

Parametrics

DS80C320QCL absolute maximum ratings: (1)Voltage on Any Pin Relative to Ground: -0.3V to (VCC + 0.5V); (2)Voltage on VCC Relative to Ground: -0.3V to +6.0V; (3)Operating Temperature: -40℃ to +85℃; (4)Storage Temperature: -55℃ to +125℃; (5)Soldering Temperature: 160℃ for 10 seconds; (6)Supply Current Active Mode @ 25 MHz ICC: 45 mA.

Features

DS80C320QCL features: (1)8051 pin and instruction set compatible; (2)Four 8-bit I/O ports; (3)Three 16-bit timer/counters; (4)256 bytes scratchpad RAM; (5)Addresses 64 kB ROM and 64 kB RAM; (6)Single-cycle instruction in 121 ns; (7)Uses less power for equivalent work; (8)Dual data pointer; (9)Optional variable length MOVX to access fast/slow RAM/peripherals; (10)Two full-duplex hardware serial ports; (11)13 total interrupt sources with six external; (12)Available in 40-pin DIP, 44-pin PLCC and TQFP.
