Product Summary
The MIC2025-1YMM is a high-side MOSFET switch optimized for general-purpose power distribution requiring circuit protection. The MIC2025-1YMM is internally current limited and have thermal shutdown that protects the device and load. The MIC2025-1YMM offers smart thermal shutdown that reduces current consumption in fault modes. When a thermal shutdown fault occurs, the output is latched off until the faulty load is removed. Removing the load or toggling the enable input will reset the device output.
Parametrics
MIC2025-1YMM absolute maximum ratings: (1)Supply Voltage (VIN): -0.3V to 6V; (2)Fault Flag Voltage (VFLG): +6V; (3)Fault Flag Current (IFLG): 25mA; (4)Output Voltage (VOUT): +6V; (5)Output Current (IOUT): Internally Limited; (6)Enable Input (IEN): -0.3V to VIN +3V; (7)Storage Temperature (TS): -65℃ to +150℃.
Features
MIC2025-1YMM features: (1)140mΩ maximum on-resistance; (2)2.7V to 5.5V operating range; (3)500mA minimum continuous output current; (4)Short-circuit protection with thermal shutdown; (5)Fault status flag with 3ms filter eliminates false assertions; (6)Undervoltage lockout; (7)Reverse current flow blocking (no body diode); (8)Circuit breaker mode (MIC2075)reduces power consumption; (9)Logic-compatible input; (10)Soft-start circuit; (11)Low quiescent current; (12)Pin-compatible with MIC2525; (13)UL File E179633.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MIC2025-1YMM |
|
IC DISTRIBUTION SW SGL 8-MSOP |
Data Sheet |
|
|
||||||||||||||
|
MIC2025-1YMM TR |
|
IC DISTRIBUTION SW SGL 8-MSOP |
Data Sheet |
|
|
||||||||||||||
